Brand: GREAT-BOOM

Model: LS18T/24T/30T-610mm-HBM-1

Engine: 6.5 horsepower, 4 stroke, OHV, air cooled

             6.5 horsepower, 4 stroke, OHV, air cooled

             9.0 horsepower, 4 stroke, OHV, air cooled

Engine Brand: LIFAN, KOHLER, B&S

Start: manual (recoil) start

Professional Log Stripper: with

Log Holder Arm: with

Hydraulic Cylinder Size: 101.60mm diameter x 610mmstroke;

                                          114.30mm diameter x 610mmstroke;

                                          127.00mm diameter x 610mmstroke

Oil Capacity: 20 liters

Gear Pump: 2 stage 11GPM flow;

2 stage 11GPM flow;

2 stage 16GPM flow

Valve: automatic return control valve with safety release function

Maximum Splitting Force: 18Ton, 24Ton, 30Ton

Wedge Height: 8 inch (200mm)

Split and Return Cycle Time: 10 seconds

                                                13 second

                                                13 second

Maximum Log Length: 24 inch (610mm)

Working Position: horizontal & vertical

Wheels and Tires: 16 inch pneumatic x 4.8 inch

Mudguard: with

Coupler:50mm cast steel with safety chains

Maximum Recommended Towing Speed: 25km/h

Package Diameter: 210cmx51cmx45cm

Package Weight: 252KGS 260KGS 278KGS

Warranty: 24 months

If Iron Frame Package: 40PCS / 40PKGS / 20GP; 88PCS / 88PKGS / 40HQ
