Specification:

7 horsepower gasoline engine, Euro V emission standard

Empty travel: 5 seconds (forward + return)

1.5 tons of firewood in 1 hour (theoretical value)

400mm cylinder stroke

520 mm maximum firewood can be split

350mm-400mm diameter wood can be split

European trailer ball joint

CE standard two-hand control valve

CE safety cover is equipped

CE operation tray is equipped, size: 480mm (L) x 380mm (W)

Operating height 770 mm

11 Gallon Bipolar Pump - DELI Brand

Control valve - DELI brand

Cylinder seals - made in the USA, bearing a temperature 125 °C

Tires: 400mm diameter, 400-8

Trailer speed 25KM/h

Machine expanded size: 1900*880*1250mm

Machine packing size: 1400*390*510mm

Machine packing material: plywood, 10mm thickness, 1 set/carton

Packing quantity: 88 sets/20FT; 230 sets/40HQ
