| Machine size（mm） | 90*1700*3300 |
| Matching power rated power | 18.3-36.7KW |
| Matching power rated speed | 2400r/min |
| Working width | 1000-1300mm |
| Speed change mechanism type | Hydrostatic continuously variable transmission |
| Rotary tillage device connection method | All-in-one |
| Working parts transmission mode | Intermediate gear |
| Braking method | Hydraulic system |
| Roller tiller blade model | 1s195 |
| Total number of knives installed on the knife roller | 26 |
| Roller speed | High speed 320, low speed 240 |
| gauge | 540mm |
| track | 180*72*40 Lace Tracks |
| Machine quality | 1200kg |
| Minimum ground clearance | 180mm |
| Deep cultivation | 250mm |
| Fuel consumption rate | 15kg/hm3 |
| Operation speed | 2km/h |
| Scope of application | Greenhouses, orchards, vegetable fields, hills, paddy fields, etc. |
| Fuselage rotation angle | 360° |
| How it works | Manual/remote control |
| Bucket | 370/350mm |
| Hip digging | 2400mm |
| Hip lift | 2500mm |
| Digging Deep | 1600mm |
